AirVac AV625 Central Vacuum Motor
$277.00
MT:0025-AirVac AV625
Please Make Sure to
Double-check the Motor Number Before you Purchase.
Double-check the Motor Number Before you Purchase.
If you are Not Sure if this Motor Will Fit Your Unit,
Please Call
Please Call
1-800-322-2965 Before you Purchase.
Motors are Non-Refundable
The AirVac AV625 Central Vacuum Motor is a replacement motor designed for AirVac AV625 central vacuum systems. The AV625 is a 220–240-volt unit that uses two motors, with the Ametek-Lamb 117123 being a commonly specified replacement. This 3-stage, 5.7-inch bypass motor provides strong suction and airflow to restore your central vacuum system's performance.
Attention Consumer
Ametek-Lamb recommends replacing your carbon brushes and motor gaskets routinely to prolong the life of your new motor. Stock up now, have your supplies on hand.
Easy Ordering
As Simple As 1-2-3
As Simple As 1-2-3
1SELECT PRODUCT OPTIONS
The Ametek-Lamb 117123 is a commonly used replacement motor for the AirVac AV625. It is a 3-stage, 240-volt bypass motor with a 5.7-inch fan diameter, tangential air discharge, and ball-bearing construction. The motor is rated at approximately 95.1 CFM, 137.1 inches of waterlift, 448 Air Watts, and 6.8 amps.
Since the AirVac AV625 uses two motors, replacing both at the same time may be worth considering when one motor fails, particularly if the existing motors have similar operating hours. This can help maintain balanced performance and avoid another motor replacement shortly afterward.
When installing a replacement motor, inspect the motor gasket, carbon brushes, wiring connections, and mounting hardware. A new or properly seated motor gasket helps maintain an airtight seal and prevents suction loss. Avoid overtightening the motor mounting screws, as excessive pressure can potentially interfere with the motor fan.
Key Features
- Replacement motor for AirVac AV625 central vacuum systems
- 220–240 volt operation
- Two motors required for the AV625 system
- Common replacement: Ametek-Lamb 117123
- 3-stage motor design
- 5.7-inch fan diameter
- Bypass motor construction
- Tangential air discharge
- Ball-bearing construction
- Approximately 95.1 CFM
- Approximately 137.1 inches of waterlift
- Approximately 448 Air Watts
- Approximately 6.8 amps
- Designed to restore suction and central vacuum performance
| Replacement Part Type | Motors |
|---|---|
| Voltage | 240 |
| Carbon Brush | 33410-3 |
| Motor Stages | 2 |
| Motor Speeds | 1 |
| Motor Type | Series Universal |
| Motor Frequency | 50/60Hz |
| Motor Fan Diameter | 7.200 |
| Fan System Style | Bypass |
| Air Discharge | Tangential |
| Motor Low Temp | 32.000 |
| Motor High Temp | 104.000 |
| Motor Bearing | Ball |
| Motor Comm Bracket Material | Plastic |
| Motor Fan Bracket Material | Plastic |
| Motor Insulation Class | A |
| Motor Fan Shell Coat | none |
| Motor Duty Cycle | Intermittent |
| Motor Electrical Connection | Lead Wires |
| Weight (lbs) | 9.000000 |
Product Description
Product Specifications
Download Instructions
Product Videos
Product Reviews
Read about the 117157 Ametek Lamb Motor
The Ametek-Lamb 117123 is a commonly used replacement motor for the AirVac AV625. It is a 3-stage, 240-volt bypass motor with a 5.7-inch fan diameter, tangential air discharge, and ball-bearing construction. The motor is rated at approximately 95.1 CFM, 137.1 inches of waterlift, 448 Air Watts, and 6.8 amps.
Since the AirVac AV625 uses two motors, replacing both at the same time may be worth considering when one motor fails, particularly if the existing motors have similar operating hours. This can help maintain balanced performance and avoid another motor replacement shortly afterward.
When installing a replacement motor, inspect the motor gasket, carbon brushes, wiring connections, and mounting hardware. A new or properly seated motor gasket helps maintain an airtight seal and prevents suction loss. Avoid overtightening the motor mounting screws, as excessive pressure can potentially interfere with the motor fan.
Key Features
- Replacement motor for AirVac AV625 central vacuum systems
- 220–240 volt operation
- Two motors required for the AV625 system
- Common replacement: Ametek-Lamb 117123
- 3-stage motor design
- 5.7-inch fan diameter
- Bypass motor construction
- Tangential air discharge
- Ball-bearing construction
- Approximately 95.1 CFM
- Approximately 137.1 inches of waterlift
- Approximately 448 Air Watts
- Approximately 6.8 amps
- Designed to restore suction and central vacuum performance
-
