AstroVac SR-89 Motor
$277.00
MT:0025-AstroVac SR-89
Please Make Sure to
Double-check the Motor Number Before you Purchase.
Double-check the Motor Number Before you Purchase.
If you are Not Sure if this Motor Will Fit Your Unit,
Please Call
Please Call
1-800-322-2965 Before you Purchase.
Motors are Non-Refundable
The Ametek-Lamb 117123 is a replacement motor designed for the AstroVac SR-89 central vacuum system. This powerful 240-volt, 3-stage, 5.7-inch bypass motor delivers strong vacuum performance with approximately 95.1 CFM, 137.1 inches of water lift, and up to 448 air watts. The AstroVac SR-89 uses two motors, so verify your existing motor number and configuration before ordering.
Attention Consumer
Ametek-Lamb recommends replacing your carbon brushes and motor gaskets routinely to prolong the life of your new motor. Stock up now, have your supplies on hand.
Easy Ordering
As Simple As 1-2-3
As Simple As 1-2-3
1SELECT PRODUCT OPTIONS
Restore your AstroVac SR-89 central vacuum's cleaning performance with a compatible Ametek-Lamb 117123 replacement motor. Designed for high-performance central vacuum applications, this 240-volt, 3-stage bypass motor features a compact 5.7-inch fan diameter while delivering powerful airflow and suction.
The 117123 motor is rated at approximately 1,500 watts and can produce up to 95.1 CFM of airflow, 137.1 inches of sealed water lift, and 448 maximum air watts. Its bypass design helps provide dependable cooling and performance in central vacuum applications.
The AstroVac SR-89 is a dual-motor central vacuum, meaning the system uses two motors. If one motor has failed, inspect the second motor as well, as both motors may have experienced similar operating hours and wear. Before ordering, always compare the motor number, voltage, dimensions, electrical connections, and mounting configuration with your original motor to ensure proper compatibility.
Replacing a worn motor can help restore the suction and airflow your AstroVac central vacuum system needs for effective whole-home cleaning.
Key Features
- Replacement motor for the AstroVac SR-89
- Ametek-Lamb 117123 motor
- 240-volt operation
- 3-stage motor design
- 5.7-inch fan diameter
- Bypass motor design
- Approximately 1,500 watts
- Up to 95.1 CFM airflow
- Up to 137.1 inches of water lift
- Up to 448 maximum air watts
- AstroVac SR-89 uses two motors
- Always verify your original motor number before ordering
| Replacement Part Type | Motors |
|---|---|
| Voltage | 240 |
| Carbon Brush | 33410-3 |
| Motor Stages | 2 |
| Motor Speeds | 1 |
| Motor Type | Series Universal |
| Motor Frequency | 50/60Hz |
| Motor Fan Diameter | 7.200 |
| Fan System Style | Bypass |
| Air Discharge | Tangential |
| Motor Low Temp | 32.000 |
| Motor High Temp | 104.000 |
| Motor Bearing | Ball |
| Motor Comm Bracket Material | Plastic |
| Motor Fan Bracket Material | Plastic |
| Motor Insulation Class | A |
| Motor Fan Shell Coat | none |
| Motor Duty Cycle | Intermittent |
| Motor Electrical Connection | Lead Wires |
| Weight (lbs) | 9.000000 |
Product Description
Product Specifications
Download Instructions
Product Videos
Product Reviews
Read about the 117157 Ametek Lamb Motor
Restore your AstroVac SR-89 central vacuum's cleaning performance with a compatible Ametek-Lamb 117123 replacement motor. Designed for high-performance central vacuum applications, this 240-volt, 3-stage bypass motor features a compact 5.7-inch fan diameter while delivering powerful airflow and suction.
The 117123 motor is rated at approximately 1,500 watts and can produce up to 95.1 CFM of airflow, 137.1 inches of sealed water lift, and 448 maximum air watts. Its bypass design helps provide dependable cooling and performance in central vacuum applications.
The AstroVac SR-89 is a dual-motor central vacuum, meaning the system uses two motors. If one motor has failed, inspect the second motor as well, as both motors may have experienced similar operating hours and wear. Before ordering, always compare the motor number, voltage, dimensions, electrical connections, and mounting configuration with your original motor to ensure proper compatibility.
Replacing a worn motor can help restore the suction and airflow your AstroVac central vacuum system needs for effective whole-home cleaning.
Key Features
- Replacement motor for the AstroVac SR-89
- Ametek-Lamb 117123 motor
- 240-volt operation
- 3-stage motor design
- 5.7-inch fan diameter
- Bypass motor design
- Approximately 1,500 watts
- Up to 95.1 CFM airflow
- Up to 137.1 inches of water lift
- Up to 448 maximum air watts
- AstroVac SR-89 uses two motors
- Always verify your original motor number before ordering
-
