Drainvac Wireless Receiver Kit (KIT-REC120)
R:0002
The Drainvac KIT-REC120 Wireless Reciever gives you the ability to extend the range of the wireless system (hose). This receiver is designed to be used with the Drainvac BL-RF34 Central Vacuum Hose. The KIT-REC120 requires electrical power from a 120 v plug in wall adapter and can be installed in any location close to a 120v electrical receptacle with the provided mounting hardware. If you have any questions please call 1-800-322-2965 and one of our central vacuum experts will be happy to assist you.
- Qty Per Pack 1
Instructions for the Drainvac/VacuVision Wireless Reciever
1. Install the RF915 components as per the installation instruction manual.
2. Programming the hose handle.
- Place the three-way switch of the hose to the off position.
- Insert the hose end into the vacuum inlet valve.
- Connect the hose to high voltage via direct connect contacts in the inlet valve or inserting cord end into the electrical outlet.
- Press the small black button on the top edge of the wireless receiver. The green light on the front should light up.
- Move the three-way switch on the hose to the right position for approximately one second. The green light on the receiver should turn off.
- Move the three-way switch to the off position.
- Then move the three-way switch to the right position. The central vacuum should activate.
| Qty Per Pack | 1 |
|---|
Product Description
Product Specifications
Read about the Wireless Receiver By Drainvac
Instructions for the Drainvac/VacuVision Wireless Reciever
1. Install the RF915 components as per the installation instruction manual.
2. Programming the hose handle.
- Place the three-way switch of the hose to the off position.
- Insert the hose end into the vacuum inlet valve.
- Connect the hose to high voltage via direct connect contacts in the inlet valve or inserting cord end into the electrical outlet.
- Press the small black button on the top edge of the wireless receiver. The green light on the front should light up.
- Move the three-way switch on the hose to the right position for approximately one second. The green light on the receiver should turn off.
- Move the three-way switch to the off position.
- Then move the three-way switch to the right position. The central vacuum should activate.
-
